Types of Containers

Flowering Container Box

Sizes

20′ Unit: 20’x8’x9.5′ (LxWxH)
40′ Unit: 40’x8’x9.5′ (LxWxH)

Whats Included

  • Fully Insulated Shell

  • Man Door (for easy access)

  • Fully Automated Hydroponic Drip System (non-recirculating)

  • (11) 3’x6′ Hydroponic Flood Tables

  • Aluminum Table Frames

  • Climate Control

  • (15) LED Fixtures (comparable to1000w DE HPS)

  • (8) High Power Oscillating Fans

  • Air Sanitation and Contamination Prevention System

  • Remote Control

  • Smart Phone Integration

Add-Ons

  • Stainless Steel Work Bench

  • Stainless Steel Sink

  • Co2 Injection System

  • Nutrient Doser

  • Security Cameras

Specifications (40′ Unit):

  • Footprint (sq ft): 320 sq ft

  • Interior Footprint: 288 sq ft

  • Flowering Canopy: 205 sq ft

  • Maximum kwh/day: 420 kwh

  • Power Connection: Lex 5-Wire CamLock

  • Max Current: 122 amps

  • Functional Ambient Temperature Range: Below 0 Degrees to 110 Degrees

Vegatative Container Box

Sizes

20′ Unit: 20’x8’x9.5′ (LxWxH)
40′ Unit: 40’x8’x9.5′ (LxWxH)

Whats Included

  • Fully Insulated Shell

  • Man Door (for easy access)

  • Fully Automated Hydroponic Drip System (non-recirculating)

  • (4) 4’x8′ Hydroponic Flood Tables

  • (1) 4’x4′ Hydroponic Flood Table

  • Aluminum Table Frames

  • Climate Control

  • (48) 25w LED Light Bars

  • (8) High Power Oscillating Fans

  • Air Sanitation and Contamination Prevention System

  • Remote Control

  • Smart Phone Integration

Add-Ons

  • Stainless Steel Work Bench

  • Stainless Steel Sink

  • Co2 Injection System

  • Nutrient Doser

  • Security Cameras

Specifications (40′ Unit):

  • Footprint (sq ft): 320 sq ft

  • Interior Footprint: 288 sq ft

  • Vegetative Canopy: 144 sq ft

  • Maximum kwh/day: 260 kwh

  • Max Current: 59 amps

  • Power Connection: 60 amp Pin & Sleeve

  • Functional Ambient Temperature Range: Below 0 Degrees to 110 Degrees

Drying Container Box

Sizes

10′ Unit: 10’x8’x9.5′ (LxWxH)
20′ Unit: 20’x8’x9.5′ (LxWxH)
40′ Unit: 40’x8’x9.5′ (LxWxH)

Whats Included

  • Fully Insulated Shell

  • Man Door (for easy access)

  • Stainless Steel Drying Wire

  • Climate Control

  • Dehumidification

  • Air Sanitation and Contamination Prevention System

Add-Ons

Stainless Steel Table

Security Cameras

Specifications (40′ Unit):

  • Footprint (sq ft): 320 sq ft

  • Interior Footprint: 288 sq ft

  • Estimated Dry Weight Capacity: Call for break down

  • Maximum kwh/day: 160 kwh

  • Max Current: 42 amps

  • Power Connection: 50 amp Twist Lock

  • Functional Ambient Temperature Range: Below 0 Degrees to 110 Degrees

Curing Container Box

Sizes

10′ Unit: 10’x8’x9.5′ (LxWxH)
20′ Unit: 20’x8’x9.5′ (LxWxH)
40′ Unit: 40’x8’x9.5′ (LxWxH)

Whats Included

  • Fully Insulated Shell

  • Man Door (for easy access)

  • Stainless Steel Drying Wire

  • Climate Control

  • Dehumidification

  • Air Sanitation and Contamination Prevention System

Add-Ons

Stainless Steel Table
Security Cameras

Specifications (40′ Unit):

  • Footprint (sq ft): 320 sq ft

  • Interior Footprint: 288 sq ft

  • Estimated Dry Weight Capacity: Call for break down

  • Maximum kwh/day: 207 kwh

  • Max Current: 49 amps

  • Power Connection: 50 amp Twist Lock

  • Functional Ambient Temperature Range: Below 0 Degrees to 110 Degrees

If you would prefer a custom idea, we can make it a reallity for you



Multi-Unit and Custom Design

Multi-Unit Facility:

All Container Units can be used with one another to form a growing facility. This facility can be made up of several self-standing units, or the units can be combined to make one open, or partitioned facility.

Example Facility Configurations:

  • 4 Flower Units, 1 Vegetation Unit, and 1 Cure/Dry Unit6 Total Containers

  • 1 Two Tiered Flower System, and 1 Vegetation/Dry/Cure Combo2 Total Containers

  • 3 Total Containers: 1 Dry/Cure Unit, and 2 Kitchen Units

Custom Design:

Interested in a unit but it is not quite to your specifications?

Custom projects include but are not limited to:

  • All-Inclusive Units

  • Dry/Cure Combos

  • 10′ units and 53′ units

  • Two-tiered growing systems

  • Processing Labs

  • Kitchens

  • Non-insulated units
